AXLE 15MM INSPYRE CONCORDE V3 2025
The 15mm Inspyre axle is specially designed to integrate a 15mm thru-axle configuration with a hub on the Inspyre Concorde V3 2025 frame.
The axle is made from 7075-T6 aluminum and has been specifically developed for the Inspyre Concorde V3 2025, which features Swell V2.1 dropouts. Its length of 133mm has been carefully optimized to ensure the best fit on the frame dropouts, enhancing the rear triangle's stiffness while maintaining the necessary space for perfect hub compression in the frame, without the need for additional spacers.
The axle also ensures excellent bike performance, offering perfect support on the frame thanks to the wide cones at both ends. Using a 15mm thru-axle setup also simplifies the installation and removal of the rear wheel.
INSTALLATION - ASSEMBLY
To install this axle, simply remove the 15-10mm reducing cones provided with the frame, replace your 10mm hub with a 15mm hub, and install the 15mm thru-axle using an 8mm Allen key. And you're all set!
SPECIFICATIONS
WARRANTY & RECOMMENDATIONS
INSPYRE BICYCLES advises against using any other axle model on the Inspyre Concorde V3 2025, as it may void the frame warranty and could result in accidents or damage to the bike and the rider. It is also recommended to have the installation checked by a professional.
